Dc Solar Surge Protector SPD
SPD
Rs8500.00Rs8000.00
40kA DC Solar SPD | 1500VDC Surge Protection Device for PV Systems
EKU5-T2-40 PV SPD is DC surge protector specially designed for photovoltaic power supply systems.Max continuous operating voltage reach DC1500V.These units must be installed in parallel on the DC networks to be protected and provide common and different modes protection. Its installed location are recommended at both ends of the DC power supply line (solar panel side and inverter/converter side), especially if the line routing is external and long.
Technical Data
Model and Specification | EKU5-T2-40PV |
|
| |
Rated Voltage (VDC) | 1000 |
|
| |
Continuous Operation Voltage (VDC) | 1,100V |
|
| |
Voltage Protection Level of Up | 3.6 |
|
| |
Nominal Discharge Current In (8/20μs) | 20KA | |||
Maximum Discharge Current Imax (8/20μs) | 40KA | |||
Reaction Time | ＜25ns | |||
Width/Pole | 18mm | |||
Shell Material | PBT | |||
Ambient Temperature | -40℃-80℃ | |||
Fuse or Circuit Breaker Matched | 25A | |||
Terminal Specification | Line | 2.5~35mm2 | ||
PE | 2.5~35mm2 | |||
Signal | 1.5mm2 | |||
No.of Pole | V+/PE/V- | |||
Protection Degree | IP20 | |||
Mounting | DIN rail 35mm | |||
Network System | PV | |||
Signal Terminal | Available | |||
